| VIDEO |
| Image Sensor: 1/3-inch CMOS Image Sensor |
| Definition: 2K QuadHD |
| Compression: H.265, H.264 |
| Lens: 1.7mm/F2.0 wide angle |
| Angle of View：166° |
| Shutter Speed: 1/25~1/100,000 /s |
| Frame Rate: 1 ~ 25 FPS |
| Bit Rate: 32Kbps ~ 2.0Mbps |
| Video Stream: FHD/hD/SD tripple stream |
| Function: D-WDR，Mirror，Snapshot |
| Detection Range: 100° (Max 5m) |
| Sensitivity: 5 level sensitivity settable |
| Drawing Speed: within 1s |
| Recording Type: Event recording and full day recording |
| Storage: MicroSD Card (Max128G) / Cloud storage |
| AUDIO |
| Pick up Device: Microphone |
| Speaker: Support |
| Intercomm: Full dulplex 2-way audio with noise cancellation |
| Power |
| Power Input 1: DC5V 1A (from Micro USB) |
| Power Input 2: 8V-24V AC (from doorbell hard wire) |
| Power Input 3: DC 12V (from power adapter) |
| CONNECTIVITY |
| Connection Type: WiFi (2.4GHz ~ 2.4835 GHz) |
| WiFi Protocol: IEEE802.11b/g/n |
| Network Protocol: TCP/IP, HTTP, DHCP, DNS |
| Chime Connection: Radio Frequency 433MHz~866MHz |
| GENERAL |
| Working Temp.: -20°~ 50°C |
| Humidity: ＜90% (No consendation) |
| Storage: MicroSD Card (Max128G) / Cloud storage |
| Size: 145×45×26mm |
| Net Weight: 105g |
| Compatible OS: Android, iOS |
